Chelsea
a stylish amenity lantern
Chelsea’s superior photometric performance makes it a popular choice for campus environments and regeneration schemes.
With a contemporary design aesthetic and uncompromising performance. Chelsea is crafted using the finest locally sourced materials in the UK, which ensures not only exceptional quality, durability, and performance but also a reduced carbon footprint.
Product specifications
-
Warranty
12 years -
Certification
CE, UKCA, Triple E -
Electrical Class
Class 1 -
IP Rating
Optic bowl: IP66, Gear compartment: Up to IP65 -
IK Rating
IK10++ -
Mounting Height
4 - 8m -
Mounting
Base casting to suit a 76mm post top. -
Applications
Residential roads, Town centres, Campuses, Parks, Footpaths
Lighting
-
Lumen Range (Lumens)
1,000-10,000 -
Output Power (Watts)
8-80 -
LED Quantity
Performance LED (12/24), Performance COB (1), Comfort COB (1), Braun Gas Effect (6) -
Colour Temperature (Kelvin)
2700K, 3000K, or 4000K -
L90 Lifetime Estimate (Hours)
>100,000
Power and Controls
-
Drive Current Range
<950mA -
Surge Protection
10kV (Standard) -
Controls
Compatible with all leading CMS, Miniature photocell, Part-night switching, Pre-programmed dimming
Mechanical and Installation
-
Materials
Body: Aluminium with high-pressure die cast base, Optic bowl: Frosted or clear UV stabilised polycarbonate -
Finish
Polyester powder coat -
Colour
Any RAL colour -
Operating Temperature
-20°C to '+50°C
light engines
-
Braun gas effect
For an authentic gas mantle aesthetic, and comfortable pedestrian-friendly lighting
-
Comfort COB
Low-glare, non-intrusive, pedestrian-friendly lighting that is soft, comfortable, and energy-efficient
-
Performance COB
Performance lighting with a softer aesthetic and more traditional lamp appearance
-
Performance LED
Choose for industry-leading optical performance and optimal energy savings
